Blue Spot Water

Features :

• High-Volume Capacity: Handles flows up to 10,000 LPH, making it perfect for commercial buildings, hotels, industrial facilities, and large-scale residential systems.

• Fully Automatic Control: The programmable system automatically manages essential maintenance cycles, ensuring continuous high-quality filtration with minimal effort.

• Durable and Reliable: Features a high-grade, corrosion-resistant ceramic sealing surface for a secure, long-lasting, and leak-free seal.

• Multi-Vessel Capability: Designed to manage large multi-vessel systems, such as a 4-vessel setup, ensuring consistent operation and water quality across the entire plant.

• Power Outage Protection: Retains all settings for up to three days after a power failure, ensuring your system recovers seamlessly.

• User-Friendly Interface: An easy-to-read LED display allows for simple programming and monitoring of the valve's status and regeneration schedule.

What does it do:

The F75A1 acts as the control centre for your large filter vessel, autonomously diverting water flow to perform backwash and rinse cycles based on a pre-set time schedule. This automated cleaning process restores the filter bed's efficiency, prevents channelling, and ensures optimal performance and consistent water quality without human intervention.

Good to know:

• Tank Sizing: Suitable for larger filter vessels ranging from 10 inch to 24 inch in diameter.

• Pipe Fitment: Requires a $4\text{-inch}$ Base connection to the vessel and a $1.5\text{-inch}$ Riser Pipe.

Specifications:

Category  Commercial / Industrial Filter Control Head

Brand RUNXIN

Model F75A1

Operation  Automatic (Time-Based / Programmable)

Inlet/Outlet Connection 50mm (2" M) Male Thread

Max Flow Rate 10,000 LPH (10 m3/h)

Suitable Tank Size 10"–24" Diameter

Base Connection  4"

Riser Pipe Size 1.5"

Water Pressure Range  0.15–0.6 MPa ($\approx 1.5$–6 Bar)

Water Temperature Range  5?C–50?C

Warranty Manufacturer's Standard Warranty

Maintenance:

Minimal Effort: Once the time-based backwash schedule is programmed, the valve requires minimal oversight, running autonomously to keep your system clean.

What is in the box:

Unit Size $30\text{cm}\times 25\text{cm}\times 28\text{cm}$ $4.0\text{Kg}$

Shipping Size $35\text{cm}\times 30\text{cm}\times 33\text{cm}$ $5.0\text{Kg}$

Dimensions :

• $1\times \mathbf{RUNXIN}$ F75A1 Automatic Filter Head

• Power Adapter and Manual
